JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JCVision |
| Certification: | CE ROHS |
| Model Number: | JC-32ILB |
| Document: | JCVision 32-inch Light Box ....pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 600 |
| Packaging Details: | CARTON BOX |
| Delivery Time: | 5-8WORK DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 50 |
|
Detail Information |
|||
| Brand: | JCVision | Model: | HD-352C |
|---|---|---|---|
| Product Name: | 32" Wall Light Box (Square Edge | Screen Size: | 32 Inches |
| Backlight Type: | E-LED | Resolution: | 3840 × 2160 (4K UHD) |
| Aspect Ratio: | 16:9 | Viewing Angle: | 89° / 89° / 89° (L/R/U/D) |
| Display Colors: | 16.7M | Brightness: | 300 ± 20 Cd/m² |
| Contrast Ratio: | 1200:1 | Response Time: | 6 Ms |
| Active Display Area: | 698.40 × 392.85 Mm (H × V) | Chipset: | Hisilicon Hi3751V352F Quad-Core, Up To 1.0 GHz |
| GPU: | Mali-450 MP2 | Operating System: | Android 9.0 |
| RAM: | 2 GB | Storage: | 32 GB |
| Decoding Resolution: | Up To 4K @ 60Hz | Image Rotation: | 0° / 90° / 180° / 270° Manual |
| USB Ports: | 2 × USB | HDMI: | 1 × HDMI In |
| LVDS Interface: | 1 × LVDS (single/dual Channel, 6/8-bit), Supports 3.3V/5V/12V | Ethernet: | RJ45 100M Ethernet |
| Wi-Fi: | 2.4G (802.11 B/g/n) | 4G Module: | Optional |
| Backlight Control: | Onboard 12V Support | Video Formats: | MPEG4, MPEG2, MPEG1, WMV, TS, MOV, AVI, FLV, Etc. |
| Audio Formats: | WAV, MP3, AAC, Etc. | Image Formats: | JPEG, PNG, BMP, GIF, Etc. |
| Speakers: | 2 × 8Ω 3W | Power Input: | AC 100–230V, 50/60Hz |
| Power Consumption: | ≤ 120W | Net Weight: | 8.0 Kg |
| Gross Weight: | 10.0 Kg | Carton Dimensions: | 830 × 150 × 550 Mm |
| Product Dimensions: | 725.80 × 420.30 × 29.20 Mm (including Wall Mount) | Installation: | Wall-mounted (Landscape / Portrait) |
| Operation: | 24/7 Continuous Use | ||
| Highlight: | 32-inch indoor digital signage display,E-LED backlit wall mount light box,wide viewing angle signage for retail |
||
Product Description
Product Name: JCVision 32-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Product Description:
Introducing the JCVision 32-inch Wall Light Box (Square Edge) – a compact yet powerful indoor digital signage solution perfect for retail stores, restaurants, hotels, and commercial environments where space is limited but visual impact matters.
The 32-inch E-LED backlit panel delivers 1920×1080 Full HD resolution with 300 cd/m² brightness, 1200:1 contrast ratio, and 89° ultra-wide viewing angles (L/R/U/D), ensuring clear and vibrant visuals from any direction. With a 6ms response time, it handles dynamic video content smoothly.
Powered by the Hisilicon Hi3751V352F quad-core chipset (up to 1 GHz) and Mali-450 MP2 GPU, the display runs on Android 9.0 with 2GB RAM and 32GB internal storage. It supports a wide range of video formats (MPEG4, MPEG2, WMV, MOV, AVI, etc.) and offers 1080P@60Hz video decoding.
Connectivity options include 2× USB, 1× HDMI IN, RJ45 Ethernet, and 2.4G Wi-Fi (802.11b/g/n). An optional 4G module is available for remote content management. The unit supports both horizontal and vertical wall mounting, making it ideal for digital menu boards, promotional displays, signage, and information kiosks.
Key Specifications:
-
Screen Size: 32 inch
-
Resolution: 1920×1080
-
Brightness: 300±20 cd/m²
-
Response Time: 6ms
-
OS: Android 9.0
-
RAM / Storage: 2GB / 32GB
-
Power: ≤120W
-
Dimensions (with wall mount): 725.80 × 420.30 × 29.20 mm
-
Weight: 8.0 kg (net)
