JCVision 43-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JCVISION |
| Certification: | CE ROHS |
| Model Number: | JC-43ILB |
| Document: | JCVision 43-inch Light Box ....pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 600 |
| Packaging Details: | CARTON BOX |
| Delivery Time: | 5-8WORK DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 50 |
|
Detail Information |
|||
| Brand: | JCVision | Model: | HD-352C |
|---|---|---|---|
| Product Name: | 43" Wall Light Box (Square Edge) | Screen Size: | 43 Inches |
| Backlight Type: | E-LED | Resolution: | 1920 × 1080 (2K Full HD) |
| Aspect Ratio: | 16:9 | Viewing Angle: | 89° / 89° / 89° (L/R/U/D) |
| Display Colors: | 16.7M | Brightness: | 300 ± 20 Cd/m² (nits) |
| Contrast Ratio: | 1200:1 | Response Time: | 6 Ms |
| Active Display Area: | 940.90 × 529.25 Mm (H × V) | Chipset: | Hisilicon Hi3751V352F Quad-Core |
| Max Frequency: | 1 GHz | GPU: | Mali-450 MP2 |
| Operating System: | Android 9.0 | RAM: | 2 GB |
| Storage: | 32 GB | Video Decoding: | Up To 1080P @ 60Hz |
| USB Ports: | 2 × USB | HDMI: | 1 × HDMI In |
| Ethernet: | RJ45 100M Ethernet | Wi-Fi: | 2.4G (802.11 B/g/n) |
| LVDS Interface: | 1 × LVDS (single/dual Channel, 6/8-bit) | Backlight Control: | 12V Onboard |
| Image Rotation: | 0° / 90° / 180° / 270° Manual | 4G Module: | Optional (Universal 4G) |
| Video Formats: | MPEG4, MPEG2, MPEG1, WMV, TS, MOV, AVI, FLASH, Etc. | Audio Formats: | WAV, MP3, ACC, Etc. |
| Image Formats: | JPEG, PNG, BMP, GIF, Etc. | Speakers: | 2 × 8Ω 3W |
| Power Input: | AC 100–230V, 50/60Hz | Power Consumption: | ≤ 120W |
| Net Weight: | 15.0 Kg | Gross Weight: | 18.0 Kg |
| Carton Dimensions: | 1065 × 150 × 675 Mm | Product Dimensions: | 968.60 × 556.80 × 29.20 Mm (including Wall Mount) |
| Nstallation: | Wall-mounted (Landscape / Portrait) | Operation: | 24/7 Continuous Use |
| Highlight: | 43-inch indoor digital signage display,E-LED backlit wall mount light box,wide viewing angle retail signage |
||
Product Description
Product Name: JCVision 43-Inch Indoor Digital Signage Display – E-LED Backlit, Wide Viewing Angle, Wall Mount Light Box for Retail & Hospitality (HD-352C)
Product Description:
Upgrade your visual displays with the JCVision 43-inch Wall Light Box (Square Edge) – a sleek, high-brightness digital signage solution designed for modern retail, hospitality, and commercial environments.
Crisp & Clear Display
Featuring a 43-inch E-LED backlit screen with a full 1920×1080 resolution, this light box delivers vivid and sharp images. With 16.7 million display colors, 1200:1 contrast ratio, and 300 cd/m² brightness, visuals remain bright and true-to-life from any angle – thanks to its 89/89/89/89° viewing angle (L/R/U/D).
High-Performance Hardware
Powered by the Hisilicon Hi3751V352F quad-core chipset (1 GHz max frequency) and Mali-450 MP2 GPU, the HD-352C runs smoothly on Android 9.0, ensuring fast responses and wide compatibility with most video formats and decoding needs.
Seamless Integration
The active display area measures 940.90×529.25 mm (H×V) with a 6ms response time, making it ideal for dynamic ads, informational signage, or promotional displays. Its square-edge wall-mountable design blends perfectly into any professional setting.
Reliable & Ready to Use
Whether you're showcasing products, menus, or brand stories, the JCVision 43" Light Box delivers consistent performance with a sleek, space-saving form factor.
