3.5mm Bezel 2x2 Seamless LCD Video Wall 46 Inch Ultra Narrow Frame
Product Details:
| Place of Origin: | China |
| Brand Name: | JCVISION |
| Certification: | yes |
| Model Number: | JC-VW460 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2pcs |
|---|---|
| Delivery Time: | 15 |
| Payment Terms: | T/T |
|
Detail Information |
|||
| Color: | Black | Pixel Pitch: | 3.5mm |
|---|---|---|---|
| Size: | 46INCHES | Function: | SDK |
| LCD Brand: | BOE | External Control: | RS232 |
| Brightness: | 500cd/m2 | Certificate: | FCC, CE, RoHS |
| Contrast Ratio: | 4000:1 | Viewing Angle: | 178/178 |
| High Light: | Narrow Frame seamless lcd video wall,2x2 seamless lcd video wall,3.5mm Bezel lcd video wall |
||
Product Description
good price panel 2x2 video wall lcd video wall 46 Inch 3.5mm Bezel seamless lcd video wall
>>Product key features:
1, Ultra narrow frame design, the narrowest bezel is 0.88mm and the bezel can be optional.
2, Wall mounted, floor standing, floor standing cabinets and front push hydraulic Pop out optional.
3, The front: the shell adopting black matt anti magnetic unique and exquisite strong in anti interference;
4, Interfaces: 2xHDMI input,DP loop in,DP loop out,DVI input, VGA input,CVBS loop,USB,Switch, Power port;
5, Accessories: English manual, hanger, RS232-RJ45 converter, English IR controller, RJ45 cables, software USB
sticker
6, Working Temperature: 0°C~50°C.Working Humidity: 20%-80%;
7, Application areas: real estate sale center, clothing store, ticketing center, hotel lobby, mobile phone shop,
restaurant;
8, Video wall screen with 1080P HDMI input daisy chain controller board;
9, HDMI splitter to combine the screens to a big wall;
10, Quality SPCC video wall racks for 46” lcd videowall with complete accessories.
| Item No. | Components | Descriptions | |
| 1 | 40" BOE 8mm bezel | 500nits brightness,WLED Backlit,with 1080P HDMI input | |
| 2 | System controller | 1 in 16output HDMI splitter | |
| 3 | Bracket | POP out bracket for 46" lcd video wall | |
| 4 | Standard Accessories | English Manual,IR Controller,Power Cables,RJ45 Cables,RS232-RJ45 Connector | |
| 5 | Packing | 4/5 screens in 1 wooden case | |
| Panel Specifications | |||
| LCD Technology | Original BOE DID LCD | ||
| Active Screen Diagonal | 46" | ||
| Panel Dimension(WxH) | 1664.84*944.56 | ||
| Total Bezel Width | 8mm | ||
| Aspect Ratio | 16:9 | ||
| Physical Resolution | 1920*1080 | ||
| Backight System | WLED | ||
| Luminance(nits) | 500cd/㎡ | ||
| Contrast | 1500:1 (typ.) | ||
| Viewing Angle | H 178°|V 178° | ||
| Display Colors | 8Bit,16.7M | ||
| Refresh Rate | 60Hz | ||
| Response Time | <=6ms | ||
| Life(hrs) | >60,000(hrs) | ||
| MTBF | > 100,000 h | ||
| Surface | Anti-glare | ||
| Standby Power Consumption | <3W | ||
| Maximum Power Consumption | <=200W | ||
| Power Supply | AC100~240V 50/60 Hz | ||
| Cooling | Low noise fans | ||
| Working Time Capacity | 7x24x365hours | ||
| Working Temperature | 0℃～50℃ | ||
| Working Humidity | 0.85 | ||
| Storage Temperature | -20-60°C | -4-140°F | ||
| Storage Humidity | 85% non-condensing | ||
| Net Weight | 26kg/unit | ||
| 1080P HDMI input daisy chain board Signal Inputs, Outputs | |||
| DP 4K loop in | 1 | ||
| DP 4K loop out | 1 | ||
| DVI-I DUAL LINK | 1 | ||
| HDMI input 2K | 1 | ||
| VGA input | 1 | ||
| RS232 IN | 1 | ||
| RS232 OUT | 2 | ||
| IR IN | 1 | ||
| AC IN | AC100-240V | ||
| Color System Support | PAL/NTSC/SECAM | ||
| Control Type | IR Remote &Software Control | ||
| Menu Language | English | ||
| Vertical/Horizontal Display | Support | ||
