FDM Plate 0.8mm Nozzle Smart 3D Printer Toy DIY JCVISION 100W
Product Details:
| Place of Origin: | SHENZHEN, CHINA |
| Brand Name: | JCVISION |
| Certification: | CE/CCC/FCC/ROHS/ISO9001 |
| Model Number: | JC-SP169 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1unit |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 Unit/Units per Month |
|
Detail Information |
|||
| Production Capacity: | 10000 Sets/month | Dimension(L*W*H): | 415*415*540mm |
|---|---|---|---|
| Voltage: | 110V/220V | Plate Type: | FDM |
| Nozzle Diameter: | 0.2mm, 0.4mm, 0.8mm(optional) | Z Axis Precision: | 0.0025mm |
| Printing Material: | PLA,ABS,PHA,PETG,TPU,PA,PC | Forming Size: | 200*200*300mm |
| Core Components: | Bearing, Gear | XY Axis Precision: | 0.0128mm |
| Nozzle Temperature: | 170-280°C | Filament Diameter: | 1.75mm |
| File Format: | STL,GCODE,JPG | Slice Software: | Cura |
| High Light: | 0.8mm Nozzle Smart 3D Printer,FDM Plate Smart 3D Printer,100W Industrial 3D Printer |
||
Product Description
JCVISION Smart 3D Printer Toy DIY Industrial 3D Printer
Product Features:
1. Linear guideway: low firction and more accuracy.
2. With LED light: feel free to check the print process.
3. 4.3''Full-color touch screen: as convenient as smart phone operation.
4. Magnetic removable extruder, easier and more efficient to change the nozzle.
5. Magnetic removable print platform: Easier for model removal without damage.
6. Power failure protection: Resume 3D print from where the last print stops due to power outage.
7. Dual motor feeding system,make printing more precise, excellent function for complicated model printing.
8. Filament run-out reminder: A friendly reminder for filament changing due to filament shortage or breakage.
9. Automatic bed leveling & automatic lifting filament tray: intelligent control of bed levelling and more time-saving for filament feeding.
Specification:
| Advantages | Fashionable appearance /Smart leveling /WIFI/ Camera monitoring / Clip-on swift change nozzle / Hot bed/LED lighting inside |
| Printing size | 200*200*300mm |
| Nozzle number | Single |
| Layer thickness | 0.05-0.30mm |
| Forming precision | ±0.1-0.3mm |
| Nozzle diameter | Standard 0.4mm(0.2mm,0.8mm optional) |
| Printing material | PLA/ABS/TPU/PHA/ PETG/PA/PC |
| Filament diameter | 1.75mm |
| Slicing software | CURA-Chinese/English |
| Support File Format | stl;Gcode;obj;dae;amf;bmp;jpg |
| XY axis precision | 0.0128mm |
| Z axis precision | 0.0025mm |
| Hot bed temperature | 0-120℃ |
| Nozzle temperature | 0-280℃ |
| SD card offline printing | Support u disk printing |
| LCD | 4.3 inch color touch screen |
| Working voltage | 24V |
| Input voltage | 220V/110V |
| Average power/maximum power | 100W/200W |
| Product size | 408*404*535mm |
| Packing size | 525*520*610mm |
| Machine weight | 17kg |
| Packing weight | 23kg |
| Environmental requirement | 15-35℃,Humidity20-50% |
| Quality certification | CE,FCC,ROHS |
| Hot bed | √ |
| Fully enclosed design | √ |
| Auxiliary leveling | √ |
| Laser engraving mode | Optional |
| WiFi connect | √ |
| HD Camera | √ |
| Bulit-in LED lighting | √ |
| Shipped with filament | √ |
| Shipped with U disk | √ |
