RJ45 Room Scheduling Touch Screen , IPS Screen Conference Room Availability Display 10Inch
Product Details:
| Place of Origin: | Made in China |
| Brand Name: | JCVISION |
| Certification: | CE,FCC,ROHS |
| Model Number: | JC-MS101 Pro |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Can be discussed |
| Packaging Details: | standard |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 60000 Piece/Pieces per Month |
|
Detail Information |
|||
| Screen Size: | 10.1" | Contrast: | 1000:1 |
|---|---|---|---|
| Keyword: | Wall Mount Meeting Room Booking Display 10 Inch POE Android | Brightness: | 350cdm2 |
| Resolution: | 1280*800 | Drive Interface: | Micro USB |
| Touch Screen Type: | Capacitive Touch Screen | Processor Type: | Quad Core |
| High Light: | RJ45 Room Scheduling Touch Screen,10Inch Room Scheduling Touch Screen,RJ45 Conference Room Availability Display |
||
Product Description
JCVISION Meeting Room Booking Display 10 Inch IPS Screen WiFi RJ45 Wall Mount POE Android Tablet With LED Light
Specification
| CPU | RK3288,Quad-core cortex A17,1.8G | ||
| RAM | 2GB | ||
| Internal memory | 8GB | ||
| Operation system | Android 8.1 | ||
| Touch screen | 10-Point capacitive touch | ||
| Display | Panel | 10.1"LCD IPS panel | |
| Resolution | 1280*800 | ||
| Active area | 216.96(H)x135.6mm(V) | ||
| Display mode | Normally black ,IPS | ||
| Viewing angle | 85/85/85/85(L/R/U/D) | ||
| Contrast ratio | 800 | ||
| Luminance | 300cd/m2 | ||
| Aspect Ratio | ,16:10 | ||
| Network | WiFi | 802.11b/g/n | |
| Ethernet | 100M/1000M ethernet | ||
| BT | BT 4.0 | ||
| Interface | Card slot | SD card | |
| USB | USB Host | ||
| Micro USB | Micro USB OTG | ||
| USB | USB for serial | ||
| RJ45 with POE | RJ45 | ||
| POE | IEEE802.3at/af | ||
| Power jack | DC power input | ||
| Earphone | 3.5mm earphone + Micphone | ||
| Media play | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4K | |
| Audio format | MP3/WMA/AAC etc. | ||
| Photo | jpeg | ||
| Others | VESA | 75x75mm | |
| Speaker | 2*1.5W | ||
| LED Light bar | LED Light bar | ||
| Camera | 2.0M/P,Front camera | ||
| Working temp | 0--40degree | ||
| Certificates | CE/FCC/RoHS | ||
| Language | Multi-language | ||
| Accessories | Adapter | Adapter,12V/1.5A | |
| User manual | yes | ||
